GTS Tower Series Online Uninterruptible Power Supply 10~20kVA

🔺Power range: 10~20kVA.
🔺Operation: 3/1,online double conversion.
🔺Input Voltage Range: 110V to 288V, with full load operation from 176V to 288V.
🔺Input Power Factor: >0.99.
🔺Frequency Range: 50Hz/60Hz, with self-adaption.

Small size with higher power density.

Digital Charger, adjustable from 1A to 5A.

12A charger for option, charging for large capacity batteries.

Full protection of overvoltage, circuit short and over temperature.

Inquire Now
  • 10-20kVA 3phase high frequency uninterruptible power supply tower type-Gottogpower
  • 10-20kVA 3phase high frequency uninterruptible power supply tower type-Gottogpower(2)

Share:

  • Introduction

  • Parameters

  • Download

Product Overview

The GTS Tower Series provides reliable and efficient power protection for a wide range of applications. With power ratings from 10kVA to 20kVA, this UPS series is ideal for environments where stable power is crucial, including government, finance, IT, education, transportation, broadcasting, medical, and energy sectors.

Key Features

  • GOTTOGPOWER three Phase in Single Phase Out Tower Uninterruptible Power Supplies(UPS) 10kVA/15kVA/20kVA.
  • Power range:10~20kVA.
Schematic diagram of a double conversion UPS

Operation: 3/1, online double conversion.

  • Intelligent battery management.
  • 3-level topology, high performance and efficiency.

Output PF=1,high load adaptability.

gottogpower-ups-vs-other-brand-ups
  • Wide range of input voltage tolerance.
  • Adapt to half-wave load.
  • Auto fault waveform recording.
  • Self-aging function to save test energy.

Applications: Government, Finance, IT, Education, Transportation, Broadcasting, Medical, Energy, etc.

modular ups application

Our Factory

GTS Tower Series Online Uninterruptible Power Supply 10~20kVA

We welcome you to visit our factory to experience the quality and performance of our products firsthand.

Model GTS010L GTS015L GTS020L
Rate Power 10kVA 15kVA 20kVA
Cold start Default output 50/60Hz
Input voltage range 190~499VAC(L-L)
Input power factor ≥0.99
Frequency range 40-70Hz
Output frequency 50/60Hz,self adaption
Output power factor 1
Rate output 220/230/240VAC
Load regulation ±1%
Output THDu ≤1%,Linear load ; ≤3%,non-linear load according to IEC62040-3
Transfer time-INV to BYP 0ms
Efficiency- normal mode Max 95%
Efficiency- ECO mode 98%
Noise (1 meter) 55dB <62dB
Overload (normal mode) 110%: 10mins; 125%: 1min; 150%: 30 seconds
Battery Model External batteries, 16-24 settable
Quantity
Max charging 5A
Rate voltage Default 192VDC, settable
Crest factor 3:1
Standard RS232, RS485, EPO
Option AS400, SNMP card, Parallel kit, USB, 12A charger, Air filter, Single Input kit, Maintenance bypass kit
Dimension,(W*D*H)mm 190*564*500
Weight (kg) 30
